Siemens PANTIX P40 Röntgenröhre mit Drehanode
Rotating anode X-ray Tube
Tube à rayons X à anode tournante
Ca. 1935
• PANTIX-Röhre

Click to enlarge
Longueur • Length • Länge : 56 cm • 22"
Diamètre • Diameter • Durchmesser : 12 cm • 4" 7/10







A : anode, K : cathode, C : anode axis, F : focal spot, W : tungsten ring
